Once you have created a Azure IaaS machine using the BizTalk Server 2013 Developer Azure Gallery Image, there is still a bit off configuration that needs to be done:

This is what your new Desktop will look like

Below are Install instruction specific to this Azure Gallery Image and my method of configuration, see the BizTalk 2013 Installation guides for complete installation instructions

Finish SQL Server Configuration

Update the SQL Server name

Open Microsoft SQL Server Management Studio and verify the SQL Server Name:

Update the SQL Server name to the name you gave your image:

using script:

sp_dropserver <old_name\instancename>;
GO
sp_addserver <new_name\instancename>, local;
GO

Example:

Set SQL Agent to Automatically Start

Open the SQL Server Configuration Manager, Verify the SQL Server Agent is set to Manual

Right Click on the SQL Server Agent and Select Properties

Click the Service Tab

Click the Start Mode and Select Automatic, Click OK

Right Click on SQL Server Agent, Click Start

Verify the SQL Server Agent is Running

Update SQL Client Protocols

In the SQL Server Configuration Manager, Disable Shared Memory for both 32 and 64 Client

In Protocols for MSSQLSERVER, enable Named Pipes and TCP/IP and disable Shared Memory

Restart SQL Server to complete changes

Configure BizTalk

Double Click on Configuration – Shortcut on the desktop, enter User Name and Password, Click Configure

Click Next, Wait for Configuration to Complete

Check the Launch Custom Configuration, if needed, Click Finish

Install LOB Adapters

From c:\BizTalkServer2013_Developer run Setup.exe, Select Install BizTalk Adapters

Install Microsoft WCF LOB Adapter SDK, by Clicking the Link and following the Wizard

Install Microsoft BizTalk Adapter Pack, by Clicking the Link and following the Wizard

Install Microsoft BizTalk Adapter Pack(x64), by Clicking the Link and following the Wizard

Install Microsoft BizTalk Adapters for Enterprise Applications (if required), by Clicking the Link and following the Wizard

Exit when complete, Add New Adapters in the Adapters section of the Platform Setting in the BizTalk Server Administration Console

Option Installation and Configuration

ESB Toolkit

From c:\BizTalkServer2013_Developer run Setup.exe, Select Install BizTalk ESB Toolkit, follow the wizard

Select the ESB Configuration from the Windows Start Screen, Enter the Database Server (name of your machine), the User Account and Password and Click ESB BizTalk Applications

Check the Enable ESB Core Components in the BizTalk Server and Click Apply Configuration

Database SQL Agent Jobs

On a developer machine I typically set all the BizTalk Databases to simple recover mode so I don’t have to configure the BizTalk Server Backup Job

DTA Purge and Archive SQL Agent Job

To keep the developer machine clean I also use the following script to just purge the DTA (Tacking) Database, This keeps 10 days of Tracking Data

declare @dtLastBackup datetime
set @dtLastBackup = GetUTCDate()
exec dtasp_PurgeTrackingDatabase 1, 10, 11, @dtLastBackup

finished the basic Then Enable the DTA Purge and Archive Job

Conclusion

This finished the basic configuration with a few extra, if you are using BizUnit, BTDF or any other tools, you will need to install them now.

I hope this instruction and screen shots help you get your BizTalk Server 2013 Developer Azure Gallery Image up and running smoothly
